Pin
No.
Mark
I/O
Division
Function
62
H1FOUT
O
H bridge 1 forward output
terminal
63
H1PG1
—
H bridge 1 power unit’s
GND 1
64
IN1F
I
H bridge 1 forward input
terminal
13. Caution in Use of Rechargeable Battery Ass'y
-
Take Rechargeable Battery Ass’y out of Battery Carrying Case and use it.
-
Be sure to carry Rechargeable Battery Carrying Case. If not, it may either heat
or ignite by shorting with a metal. (as shown in
Fig. 10
)
Fig. 10
14. Supply of Rechargeable Battery Ass'y as
Replacement Parts
Please take note of the following points relating to Battery Carrying Case to be
used for protection of Rechargeable Battery Ass’y from shorting. Replacement
Parts:
-
Rechargeable Battery Ass’y (RP-BP62EYS1) supplied will be provided with
Battery Carrying Case (RFA0475-Q).
-
No replacement parts will be supplied for Rechargeable Battery Ass’y without
Battery Carrying Case.
