terminal for EFM PLL
Pin
No.
Mark I/O
Division
Function
45 ADIP I ADIP signal input terminal
46 PEAK I Servo ADC input terminal
47 BTOM
48 BAT
49 GAIRAN
50 MON3T
51 VREFI I Servo ADC input/voltage
reference for ADIP
comparator
52 FF2 I Servo ADC input terminal
53 AVDD 0 — Analog power supply
54 FF1 I Servo ADC input terminal
55 AVSS 0 — Analog GND
56 DD I Servo ADC input terminal
57 CC
58 BB
59 AA
60 AVDD 1 — Analog power supply
61 AVSS 1 — Analog GND
62 AVSS 2
63 ADACL O Audio output terminal (L-
ch.)
64 ADACR O Audio output terminal (R-
ch.)
65 AVDD 3 — Analog power supply
(dedicated to audio DAC)
66 DVDD 1 — Digital power supply
67 DVSS 1 — Digital GND
68 SEL0 I Connected to GND
69 RVDD 2 I Power supply to internal
DRAM
70 RVSS 3 — GND to internal DRAM
71 SEL1 I Connected to GND
72,
73
TS1, TS2
74~78 MONI4
~MONI0
O Monitor signal output
terminal (4~0)
79 TS3 I Connected to GND
80 TSCTSY O Microprocessor interrupt
signal 4 output terminal
(for Monitor)
48
