Basic Operation Instructions
GC2 Controller
www.pridemobility.com
Joystick
A multi-functional tool used
to control speed and
direction.
Speed Dial
Turn to increase or decrease
maximum speed.
Battery Condition Meter
Series of five colored LEDs
which display the battery
condition and fault codes.
On/Off Key
Press to power on or off the
power chair and controller.
Horn Key
Activates a warning horn.
Off-board Charger/
Programming Port
Used to charge or program
the power base.
Figure 1. GC2 Components and Connections
