Basic Operation Instructions 9
www.pridemobility.com Remote Plus Controller
Figure 1. Remote Plus Components and Connections (3-Key Shown)
Mode Button
Used to select the various
functions available with the
Remote Plus.
On/Off Button
Press to power on or off the
power chair and controller.
BACK VIEW
Speed/Profile Indicator
Series of five colored LEDs
which display the speed or
profile setting.
Battery Condition Meter
Indicates the approximate
amount of battery life using
color-coded LED bars.
Horn Button
Activates a warning horn.
Mounting Bracket Access
An alternate Remote Plus mounting option
may be available with your power chair.
Harness Connector Port
Used to connect the Remote Plus to the
power base.
Actuator Indicators
Four LEDs indicate
recline, tilt, power leg
rests, and elevating seat
actuator modes.
Joystick
A multi-functional tool used
to control speed, direction,
and actuator adjustment.
Off-board Charger/
Programming Port
Used to charge or
program the power base.
