33
(4) Bridge Mode
The modem can be configured to act as a bridging device between your LAN and your
ISP. Bridges are devices that enable 2 or more networks to communicate as if they are 2
segments of the same physical LAN. Please set the Connection type.
The following table describes the labels in this screen.
LABEL DESCRIPTION
Encapsulation Select your encapsulation type from the dropdown list.
3.7 LAN Configuration
3.7.1 LAN Configuration
Go to Interface Setup -> LAN. The LAN option enables you to configure the LAN
port.
There are the IP settings of the LAN Interface for the device. These settings may be
referred to as Private settings. You may change the LAN IP address if needed. The
LAN IP address is provided to your internal network and cannot be seen on the Internet.
