Responding to System Events
10−2 EATON Powerware ® 9315 UPS (200–300 kVA) Operation Manual
S 164201036 Rev G www.powerware.com
INVERTER MESSAGES − NOTICES INVERTER MESSAGES − ALARMS
Over Temperature Shutdown Battery Not Charged
Clear Battery Not Charged
100% Overload Shutdown Bypass is Not Available
Bypass is Available
125% Overload Shutdown Input Breaker Open
Bypass Cont. (K2) Failure Inv. Logic Power Failure
Clear Inv. Logic Pwr Fail.
Bypass Cont. (K4) Failure Phase A Current Limit
Phase B Current Limit
Phase C Current Limit
Bypass Control Failure Load Transferred to Bypass
Inverter Cont. (K3) Failure
Inverter Failure
Load Off
Inverter Cont. (K3) Open
Bypass Cont. (K4) Failure
Bypass Mode
Normal Mode Inverter On
Inverter Off
Keyswitch On Bypass Contactor (K2) Closed
Bypass Contactor (K2) Open
Inverter Commanded On
Inverter Commanded Off Total Battery Discharge
Bypass Contactor (K4) Closed
Bypass Contactor (K4) Opened
Input Breaker (CB1) Closed
Input Breaker (CB1) Opened
Inverter Contactor (K3) Closed
Inverter Contactor (K3) Opened
Inverter Shutdown
Inverter Normal
Load Transferred to Bypass
Auto Mode
