Figure 5-4. load amps meters screen – Powerware 9315 UPS User Manual
Page 32
Using the Monitor Panel
5−6
EATON Powerware
®
9315 UPS (200–300 kVA) Operation Manual
S 164201036 Rev G www.powerware.com
Uninterruptible Power System
System Normal
Alarm: None
Notice: None
Meters
System
Load Amps
Events Statistics Graphics Setup
Meters
Output Current
125%
100%
75%
50%
25%
0%
Phase A
Phase B
Phase C
04 NOV 1997 14:23:45
Battery
100%
Percent
Figure 5-4. Load Amps Meters Screen
