12
RQT8346
Inserting a disc
[1] Press [ <, OPEN/CLOSE] on the main unit to
open the tray.
≥You can insert a cartridge or non-cartridge disc.
[2] Press [ <, OPEN/CLOSE] on the main unit to
close the tray.
Note
≥A double-sided disc should be loaded with the side you want to
record/play facing down.
≥It is not possible to record or play continuously from one side of a
double-sided disc to the other. You will need to eject the disc and
turn it over.
≥When using 8 cm (3q) DVD-RAM or 8 cm (3q) DVD-R, remove the
disc from the cartridge.
Automatic drive select function
[RAM] [Only for discs with the write-protect tab on the cartridge set to
“PROTECT” (
l 70, Cartridge-protection)] [DVD-V] [DVD-A] [VCD] [CD]
≥If the unit is stopped or recording to the HDD or VHS, it
automatically switches to the DVD drive when a disc is inserted.
≥If you eject a disc and close the disc tray, the HDD drive is
automatically selected.
The surface on which you can see a roll of tape should face up.
Insert a video cassette.
≥The unit is automatically turned on.
≥Play starts automatically if you insert a video cassette with the tab removed.
For main unit
≥Press [<, EJECT] on the main unit.
For remote control
≥Press [DRIVE SELECT] to select VHS drive and then press and hold [∫, STOP] for about 3 or more
seconds.
When the card indicator (“SD”) on the unit’s display is flashing, the card is being read from or written to. Do not turn off the unit or remove the
card. Such action may result in malfunction or loss of the card’s contents.
≥Inserting foreign objects can cause a malfunction.
≥You can use SD Memory Cards with capacities from 8 MB to 2 GB (
l 7).
Automatic drive select function
≥If you insert an SD card while the unit is stopped, the “SD Card Operations” screen is displayed. Select an item and press [ENTER] to switch to
the SD drive ( l 44, 66).
If you remove an SD card, the HDD drive is automatically selected.
(1)
(2)
(3)
Non-cartridge disc Cartridge disc
(1) Insert label-up.
(2) Insert fully so it clicks into place.
(3) Insert label-up with the arrow facing in.
Inserting a video cassette
Inserting/Removing the SD card
ADAPTER
Inserting the card
Press on the center of the
card until it clicks into place. Removing the card
(1) Press on the center of
the card.
(2) Pull it straight out.
Opening the cover
Press down. Closing the cover
Press up.
Insert the card label up with the cut-off corner on the right.
If you are using a
miniSD
TM card, insert
it into the miniSD TM
card adaptor that
comes with the card.
Insert and remove this
adaptor from the unit.
Keep the small memory cards such as the SD Memory Card out of reach of children. If swallowed, seek
medical advice immediately.
