42
Assembling and Maintaining TRM 800-Series Treadmills
Reassembling the Treadmill Fairing
After the console is in place, reattach the two cover panels of
the treadmill fairing.
Important: In the following procedure, do not allow the fasteners
to break or pinch any cables.
To reassemble the fairing:
1.
Verify that the cable assembly is secure inside the cable
clips and that the ferrite bead on the base unit data cable
is tied securely into place in the left arm of the treadmill.
2. Snap the rear cover into place and attach the seven
screws you removed with it earlier.
Figure 27: Removal and replacement of the rear fairing cover
3. Hold the center column cover in place and attach the two
screws you removed with it.
Figure 28: Removal and replacement of the center column
cover
