C h a r g e r
Input 117VAC 60Hz, 320VA (Volt Amps)
Output 24 Volts, 8 Amps DC
◆ Electronic reverse polarity and short circuit-shutdown
◆ Low voltage start (total battery voltage must be greater than 1V to
charge)
◆ AC input fuse in AC input connector
Use only NRTL-listed accessories (National Recognized
Testing Lab).
I n v e r t e r
Input Voltage 21 to 30VDC
No Load Current 0.23A
Frequency 60 Hz
Output Voltage 110VAC +5%
Output Power 300W RMS (continuous)
Surge Power 400W RMS (1 second)
Output Waveform Pure Sine Wave (THD<4%)
Typical Effeciency 75%
Operating
Temperature 32°F to 105°F (0°C to 40°C)
A-2 Specifications
