Philips Semiconductors ISP1561 Evaluation Board User’s Guide
UM10005_3 © Koninklijke Philips Electronics N.V. 2003. All rights reserved.
User’s Guide Rev. 2.0—April 2003 19 of 20
8. Bill of Materials
The following table provides the bill of materials for the ISP1561 evaluation board.
Quantity Part Type Designator Footprint Description
2 — JP3 JP4 RADO.2 —
13 0.001 µF C3 C4 C5 C6 C7 C8 C9 C10 C11
C12 C13 C16 C17 0603 —
3 0.01 µF C59 C60 C61 0603 —
29 0.1 µF C18 C19 C20 C21 C22 C23 C24
C25 C26 C27 C28 C29 C30 C31
C32 C33 C34 C35 C36 C37 C38
C39 C40 C41 C42 C43 C44 C45
C46 0603 —
6 0 Ω R22 R23 R24 R25 R26 R27 0603 —
7 100 pF C47 C48 C49 C50 C51 C54 C55 0603 —
1 100 µF/10 V C74 REC1/2 —
14 10 kΩ R1 R2 R3 R4 R5 R6 R7 R8 R9 R10
R11 R12 R13 R14 0603 —
1 12 kΩ ±1% R18 0603 —
1 12 MHz OSC1 XTAL1 30 ppm
8 15 kΩ R37 R38 R39 R40 R41 R42 R43 R44 0603 —
2 1 kΩ R20 R21 0603 —
1 2.2 µF /10 V C63 — —
1 2.2 µF /6.3 V C64 — —
4 220 µF/10 V C70 C71 C72 C73 REC1/2 —
2 22 pF C1 C2 0603 —
1 22 µF/10 V C75 REC1/2 —
1 330 Ω R19 0603 —
1 33 Ω R28 — —
1 4.7 µF/6.3 V C65 — —
1 470 pF C62 0603 —
4 47 µF/10 V C66 C67 C68 C69 CASE-D —
3 47 µF /6.3 V C56 C57 C58 CASE-D —
1 48 MHz OSC2 XTAL3 30 to 50 ppm, optional
3 4 kΩ R15 R16 R17 0603 —
8 560 Ω R29 R30 R31 R32 R33 R34 R35 R36 0603 optional
1 51 kΩ R45 0603 optional
1 AT24C01A-2.7 U1 — Atmel I 2 C-bus
EEPROM; optional
7 BLM18PG121SN1 FB1 FB2 FB3 FB4 FB8 FB9 FB10 — Murata
2 BLM31PG121SN1 FB5 FB6 1206 Murata; optional
1 BLM41PG600SN1 FB7 1206Cust Murata; optional
4 ESD ESD1 ESD2 ESD3 ESD4 — PSR05-PD10611-
Protek devices;
optional
1 HEADER 3 JP1 SIP3 Optional
1 HEADER 4X2 JP2 — Optional
1 ISP1561 U2 — Philips
1 JACK J1 — PCB mount socket pin
diameter 2.5; optional
9 LED D1 D2 D3 D4 D5 D6 D7 D8 D9 LED3 Optional
