Instruction for use Philips mini-speakers
1. Introduction
CONGRATULATIONS ! You have just bought a
sophisticated mini stereo loudspeaker set.This
set gives you the opportunity to share your
favourite music with your friends.To ensure the
best performance of your mini stereo
loudspeakers, please read this document
carefully.
2. Features
•Trackball volume control
• Built-in 2 Watt amplifier
• Easily portable
• Battery or mains operated
^
• Bass reflex system
3. Explanation of controls
1. Power on/off
2. Trackball volume control 7
3. Power indication LED
4. Bass reflex port
5. Audio input cable
6. AC/DC adaptor input
7. Output jack to left speaker
8. Audio input cable for left speaker
9. Battery cover
4. Installation
1. Connect the stereo signal to the Mini speaker
loudspeaker with the HiFi cable coming from
the right speaker as shown in figure I.
2. SBC BA 110 powered by batteries. Insert four
batteries {R6,‘AA') in the battery
compartment on the right speaker module,
ensuring that the polarity is correct (see figure
1 .)
3. SBC BAI10 powered byAC/DC adaptor.
Insert theAC/DC adaptor plug into the DC
input jack (6) on the rear of the right speaker.
Then plug theAC/DC adaptor into a standard
mains power wall outlett.The voltage
mentioned on the rating label of theAC/DC
adaptor should be in line with the voltage of
the wall outlet.
5. Operation
1. Switch on the mini speakers: the amplifier is
now activated.
2. Position both speakers so that you can enjoy
the full audio range sound.
3. Adjust the speakers' volume level control to a
comfortable listening level.
SBC BAI 10
4. When you no longer require the speakers,
turn the power switch off to conserve
batteries.
5. When the battery power runs low. the
battery indication (3) becomes less bright
and the sound quality degrades; when this
happens replace the batteries.
6. By not switching on the power the mini
speakers can be used as passive speakers; in
this case the speakers’ volume can be
controlled by adjusting the volume of your
audio source.
Positioning the mini speakers
Position the left speaker on the left side of your
listening area, and the right speaker on the right
side.
Specifications
Frequency range
Impedance passive
Impedance active
Maximum output power
Weight
Power supply
80.. 18 000 Hz
4 il
ISO il
2x2 W
685 g
4xR6(’AA') or AC/
DC adaptor 6V/500 mA
8. Precautions
•This mini speaker system works only on a 6V
DC supply. If the system has not being used
or will not be used for some time, please
remove the batteries to prevent leakage and
corrosion.
• Do not leave the mini speakers near heat
sources. Do not expose to direct sunlight,
excessive dust, moisture, rain or any kind of
mechanical shock.
• Do not use alcohol, thinner or petroleum-
based substances to clean the speakers.
• If fluid spills into the speakers, remove the
batteries immediately and consult an
authorised dealer.
• Keep the mini speakers away from TV or
credit cards using magnetic coding to prevent
any damage caused by the speakers' magnets.
