– 9 –
ITEM DESCRIPTION QUANTITY
L. Table saw assembly 1
M. Right / left table extension 1 each
N. Front table extension rail 1 set
O. Rear table extension rail 1 set
P. Hex bolts 4
Q. Table extension hardware bag 1 set
R. Front rail covers 1 set
S. Front rail hardware bag 1 set
Hex bolts - long 4
Hex bolts - short 2
Square nuts 6
T. Rear rail hardware bag 1 set
Hex bolts 6
Hex nuts 2
U. Handwheel, dome nut, handle, nut 1 each
V. Riving knife 1 set
W. Anti-kickback pawl 1
X. Blade guard 1
Y. Miter gauge 1
Z. Rip fence 1 each
AA. Blade wrench 1
BB. Push stick 1
ITEM DESCRIPTION QUANTITY
A. Leg set 1 set
Front right leg - no. 2 1
Rear right leg - no. 3 1
Front left leg - no. 5 1
Rear left leg - no. 6 1
B. Right leg support - no. 1 1
Left leg support - no. 4 1
C. Leg assembly hardware bag 1 set
Square neck bolts 22
Hex nuts 22
D. Front leg support - no. 7 1
E. Rear top leg support - no. 8 1
Rear bottom leg support - no. 9 1
F. Foot pads 1 set
G. Caster assembly bracket 1
H. Front casters / rear casters 2 each
I. Caster assembly hardware bag 1 set
Socket hex bolt - long 1
Socket hex bolt 2
Socket hex bolt - short 2
Hex nuts 3
6 mm hex key 1
WARNING !
• To avoid injury from unexpected starting or electrical
shock, do not plug the power cord into a source of
power during unpacking and assembly. The cord
must remain unplugged whenever you are adjusting/
assembling the saw.
• The saw is heavy and should be lifted with care.
Get the assistance of someone to lift and move the
saw.
• If any part is missing or damaged, do not attempt
to assemble the table saw, or plug in the power
cord until the missing or damaged part is correctly
replaced.
TABLE OF LOOSE PARTS
STAND
UNPACKING AND CHECKING CONTENTS
Carefully unpack the table saw and all its parts, and
compare against the list below and the illustration on
the next page. With the help of an assistant place the
saw on a secure surface and examine it carefully.
CARTON CONTENTS
TABLE OF LOOSE PARTS
TABLE SAW
ITEM DESCRIPTION QUANTITY
J. Storage parts
Miter guage storage 1
Rip fence storage 1 set
Power cord storage 1 set
Blade guard assembly storage 1 set
K. Storage parts hardware 1 set
Screws - long 2
Screws - short 2
Nuts 4
Screws with washers 6
