Viewfinder Indications
1 Autofocus frame (p.39)
2 Spot metering frame (p.130)
3 Focus point (p.123)
4 Flash status (p.49)
Appears when flash is available and blinks when flash is recommended but
not set.
5 Picture mode icon (p.47)
Icon for Picture mode in use appears.
.
Night Scene Portrait, \ Moving Object, q Macro, s Landscape,
= Portrait, U Normal
6 Focus indicator (p.44)
Appears when image is focused.
7 Shutter speed (p.134)
Shutter speed when capturing or adjusting (underlined when shutter speed
can be adjusted with e-dial).
8 Aperture (p.136)
Aperture when capturing or adjusting (underlined when aperture can be
adjusted with e-dial).
9 EV compensation (p.141)
Appears when EV compensation is available or in use.
Blinks slowly when compensating flash output.
Blinks quickly when compensating exposure and flash output.
Adjusted value appears where number of recordable images is shown.
1
4
11 12 13 14
5
6 7 8 9 10
2 3
