Polaroid FLM-3230TM - Manual (Page 66)

63
PC INPUT PRESET TIMMING TABLE
* The resolution and the frequencies are displayed on the screen may not exactly same as
this list.
PC / Timing Table
No. Mode Name
Resolution
H.Freq.
(KHz)
V.Freq.
(Hz)
H. Polarity
V. Polarity
Pixel
CLK
(MHz)
Hor.
Total
CLK No.
Hor.
Display
CLK No.
Hor. Bck
Porch
CLK No.
Hor. Syth
CLK No.
Vert.
Total
Line No.
Vert.
Display
Line No.
Vert. Bak
Porch
Line No.
Vert. Syc
Width
Line No.
1
VGA 70HZ
640*350
31.469
70.087
+
-
25.175 800 640 48 96 449 350 60 2
2
VGA 60HZ
640*480
31.469
59.941
-
-
25.175 800 640 48 96 525 480 33 2
3
SVGA 60HZ
800*600
35.16
56.25
+
+
36.0 1024 800 128 72 625 600 22 2
4
SVGA 60HZ
800*600
37.879
60.317
+
+
40.0 1056 800 88 128 628 600 23 4
5
XGA 60HZ
1024*768
48.363
60.004
-
-
65.0 1344 1024 160 136 806 768 29 6
6
MAC VGA
640*480
35.000
66.667
-
-
30.24 864 640 96 64 525 480 39 3
7
US TEXT
720*400
31.469
70.087
-
+
28.322 900 720 54 108 449 400 35 2
8
XGA(CVR)
1280*768
47.396
59.995
+
-
68.25 1440 1280 80 32 790 768 12 7
9
WXGA(CVR)
1360*768
47.368
59.959
+
-
72 1520 1360 80 32 790 768 15 5
