44
The screen contains the following details:
Filed Description
Private IP Enter a private IP Address of specified entry.
Private Port Enter a private Port number of the specified entry.
Type Select virtual server protocol type of the specified entry.
Public Port Enter a public Port number of the internet user to access the virtual
server.
Enabled Enable the specified entry of the virtual server.
z
Click “CANCEL” to exit from this page without saving the changes.
z
Click “APPLY” to save the information that has been entered.
3.5.6.2 Port Mapping
For some applications, you need to assign a set or a range of port to a specified local
machine to route the packets. Router allows the user to configure the needed port
mappings to suit such application.
To configure Port Mapping, click on the Port Mapping link in the left navigation bar,
show as below.
