Appendix A
Specifications
Model
DVR-400
Video Inpuit
NTSC/PAL
Operating System
None
Video Inpout
4ch composite
Video Output
2ch composite + S-Video
Vdieo Loop
4ch composite
Audio Input
1ch RCA
Audio Output
1ch RCA
Built-in Buzzer
Yes
Display Frame
120fps (NTSC) / 100fps (PAL)
Recording Framer Rate
(Quad mode)
Max. 30fps (NTSC) / Max. 25fps (PAL)
Recording Frame Rate
(Each mode)
Max. 7.5fps (NTSC) / Max. 6.25fps (PAL)
Recording Mode
Continuous, manual, event programed
Resolution (Display)
NTSC: 720*480 / PAL: 720-576
Resolution (Recording)
NTSC: 320*112, 640*224 / PAL: 320-136, 640*272
Compression Format
Motion JPEG (8-20K bytes/frane)
HDD
Swappable HDD tray (Max. HDD capacity: 250GB)
Search Mode
Time, date, camera
Netwrok
TCP/IP
Ethernet
RJ45
Watch-dog
Auto-recovery capability after power
Dimension
350 x 292 x 60 mm (W x D x H)
Weight
4.15 kg (gross weight)
