Page 52: Playback, Adjusting the playback picture, Manual tracking ∫ vertical locking adjustment

Playback
52
It is also possible to play back tapes recorded in the S-VHS system.
≥Some picture noise may occur depending on the type of tape used.
≥It is not possible to fully obtain the high resolution that S-VHS is
capable of.
≥It is not possible to record in the S-VHS system with this unit.
During play or while stopped
Keep pressing [
1, PLAY] for 5 or more
seconds.
≥The “RP” indication appears on the display.
∫ To cancel the Recorded Part Repeatedly
Press [
∫, STOP].
This unit automatically records special index signals on the tape
every time a recording is started. The Index search function makes
use of these index signals to let you find the beginning of a desired
programme quickly and easily.
While stopped or during normal play
Press [
:
] or [
9
].
≥The unit automatically starts playback after the
index signal is found.
≥Each press increases the number of skip.
∫ To cancel the Index Search or to stop playback
Press [
∫, STOP].
Note
≥Up to 20 index signals can be searched for in both directions.
≥When you press either one of the button too much, you can control
the number of skips by pressing the opposite button.
≥The figure on the display decreases by 1 each time an index signal
is located.
≥This feature may not work correctly if the marks are too close
together. Make recordings of at least 5 minutes.
The unit automatically makes tracking adjustments, but you may
need to do it manually, if noise appears on a tape recorded on other
equipment.
During normal or slow playback,
Press [TRACKING/V-LOCK,
i, j] until the bars
noise disappear.
≥If the noise bars appear during still playback, switch the VHS over
to the slow playback mode and then adjust the tracking.
∫To return to auto tracking
Press both [TRACKING/V-LOCK,
i, j] i and j simultaneously.
If the still picture shakes, perform the following operation.
During still playback,
Keep [TRACKING/V-LOCK,
i, j] pressed until the
picture stops shaking.
∫To return to auto tracking
Press both [TRACKING/V-LOCK,
i, j] i and j simultaneously.
∫To remove the noise from a paused picture
Start slow play, then adjust the tracking.
Note
≥This may not work with some TV models and tapes.
You can play back a tape in Progressive video or RGB video with TP
channel.
Preparation
Connect this unit and the TV and then set the output.
≥RGB Output
≥Progressive
[1]
Press [DVD].
[2]
Press [CH,
W, X] to select the “TP” channel.
≥About TP channel
[3]
Press [VHS] and then press [
1, PLAY].
≥The tape starts playing back in high picture quality.
Note
≥Check if the setting on “TV Aspect” is suited to the size of your TV.
(“SETUP”-“Connection”-“TV Aspect”,
≥The TV must be RGB-compliant or Progressive-compliant.
Preparation
≥Press [VHS].
≥Insert a recorded video cassette.
S-VHS Quasi Playback (SQPB)
To Play back a Recorded Part Repeatedly
VHS Index Search System (VISS)
SLOW/
SEARCH
REW
FF
DUBBING
DVD/VHS
CREATE
CHAPTER
SKIP/INDEX
PLAY
STOP
PAUSE
TRACKING/V-LOCK
AUDIO
EXT LINK
FUNCTIONS
DIRECT NAVIGATOR
TOP MENU
RETURN
SUB MENU
PROG/CHECK
VHS REC
TIME SLIP
STATUS
DVD REC
REC MODE
DVD/VHS
CANCEL/RESET
INPUT SELECT
DIRECT TV REC
TIMER
VHS
VHS
G-Code
CREATE
CHAPTER
CH
AV
VOLUME
DVD
DVD
JET REW
ENTER
DISPLAY
TRACKING/
V-LOCK,
i, j
CH,
W, X
STATUS
1
;
∫
:, 9
ENTER
µ
DVD
REC MODE
EXT LINK
VHS
Numeric
Buttons
Adjusting the playback picture
∫ Manual tracking
∫ Vertical locking adjustment
To Play back a tape in high picture quality
VHS
