Chapter4
Advanced Configuration
20 Wreless-N ADSL2+ Gateway
MAC Address
MAC Address
Enter a Name Enter a name for your device.
MAC Address Enter the MAC address of your device.
Prorty Select the appropriate priority: Hgh, Medum,
Normal, or Low. The default is Medum.
Click the Add button to save your changes. Your new entry
will appear in the Summary list.
Ethernet Port
Ethernet Port
Ethernet Select the appropriate Ethernet port.
Prorty Select the appropriate priority: Hgh, Medum,
Normal, or Low. The default is Medum.
Click the Add button to save your changes. Your new entry
will appear in the Summary list.
Voice Device
Voice Device
Enter a Name Enter a name for your voice device.
MAC Address Enter the MAC address of your voice device.
Prorty Select the appropriate priority: Hgh, Medum,
Normal, or Low. The default is Medum.
Click the Add button to save your changes. Your new entry
will appear in the Summary list.
Summary
This lists the QoS entries you have created for your
applications and devices.
Prorty This displays the bandwidth priority of Hgh,
Medum, Normal, or Low.
Name This displays the application, device, or port
name.
Informaton This displays the port range or MAC address
entered for your entry. If a pre-configured application or
game was selected, there will be no valid entry shown in
this section.
Remove Click this button to remove an entry.
Edt Click this button to make changes.
Click Save Settngs to apply your changes, or click Cancel
Changes to cancel your changes.
Administration > Management
This screen allows the network’s administrator to manage
specific Gateway functions for access and security.
Administration > Management
Gateway Access
Local Access
To ensure the Gateway’s security, you will be asked for your
User Name and password when you access the Gateway’s
web-based utility. The default User Name and password
are admn.
User Lst Select the number of the user. The default is
user .
Gateway User Name Enter the default Gateway User
Name, admn.
Gateway Password Linksys recommends that you
change the default Gateway Password, admn, to one of
your choice.
Re-Enter to Confrm Enter the Gateway Password again
to confirm.
For non-admin users, select a different user number, and
then configure the Gateway User Name and Password
settings.
