Product Overview
PowerOverEthernetAdapterKt
Splitter’s First Side Panel
The Power & Data IN port is located on the Injector’s first side panel.
Power&DataIN
This port allows you to connect the Splitter
to the Injector. (You will use the included Ethernet network
cable to make this connection.)
Splitter’s Second Side Panel
The built-in Ethernet network and Power cables are located on the
Splitter’s second side panel.
Ethernet OUT
The Splitter has a built-in Ethernet network
cable. You will connect this cable to the Ethernet network
port of your remotely located access point or other network
device.
Power
The Splitter has a built-in power cord. You will connect
this cord to the Power port of your remotely located access
point or other network device.
