Lochinvar SQUIRE SIT030 User Manual
Page 24
Revision Notes: Revision A (ECO C05265) initial release.
Revision B (ECO C05399) reflects the addition of the Pressure Drop
Chart and updates made to the Performance Data Charts.
Revision C (ECO C05587) reflects the update of tables 3A and 3B
(Pressure Drop charts) on pg 6, table 4A on pg 13, the update of the
“Domestic water piping” paragraph on pg 11, and the update of
Performance data table 8A on pg 19.
Revision D (ECO C05788) reflects new images for section 3 “Boiler Side
Piping” FIG. 3-1 -- 3-4, a new image for section 4 “Domestic Side (Tank)
Piping” FIG. 4-2, and the update of the Pressure Drop chart on page 6.
SIT-I-O Rev D
6/10 - Printed in U.S.A.
