Chapter3
Advanced Configuration
9
RangePlus Wreless Router
Category
There are four categories available. Select one of the
following: Applcatons, Onlne Games, MAC Address,
Ethernet Port, or Voce Devce. Proceed to the instructions
for your selection.
Applications
Applcatons
Select the appropriate application. If you
select Add a New Application, follow the Add a New
Application instructions.
Prorty
Select the appropriate priority: Hgh, Medum,
Normal, or Low.
Click Add to save your changes. Your new entry will appear
in the Summary list.
Add a New Application
QoS > Add a New Application
Enter a Name
Enter any name to indicate the name of
the entry.
Port Range
Enter the port range that the application will
be using. For example, if you want to allocate bandwidth
for FTP, you can enter 21-21. If you need services for an
application that uses from 1000 to 1250, you enter 1000-
1250 as your settings. You can have up to three ranges
to define for this bandwidth allocation. Port numbers
can range from 1 to 65535. Check your application’s
documentation for details on the service ports used.
Select the protocol TCP or UDP, or select Both.
Prorty
Select the appropriate priority: Hgh, Medum
(Recommend), Normal, or Low.
Click Add to save your changes. Your new entry will appear
in the Summary list.
Online Games
QoS > Online Games
Games
Select the appropriate game.
Prorty
Select the appropriate priority: Hgh, Medum
(Recommend), Normal, or Low.
Click Add to save your changes. Your new entry will appear
in the Summary list.
MAC Address
QoS > MAC Address
Enter a Name
Enter a name for your device.
MAC Address
Enter the MAC address of your device.
Prorty
Select the appropriate priority: Hgh, Medum
(Recommend), Normal, or Low.
Click Add to save your changes. Your new entry will appear
in the Summary list.
Ethernet Port
QoS > Ethernet Port
Ethernet
Select the appropriate Ethernet port.
Prorty
Select the appropriate priority: Hgh, Medum
(Recommend), Normal, or Low.
Click Add to save your changes. Your new entry will appear
in the Summary list.
Voice Device
QoS > Voice Device
Enter a Name
Enter a name for your voice device.
MAC Address
Enter the MAC address of your voice
device.
Prorty
Select
the
appropriate
priority:
Hgh
(Recommend), Medum, Normal, or Low.
Click Add to save your changes. Your new entry will appear
in the Summary list.
