Revision Comments Part Description Part No. Ref.
BLADE BOL 1 1/8-12X3 7/16 W/KY 802-277C 26.
WASHER FLAT 1 HARD ASTMF436 PN 804-147C 27.
RCR1542 S/N 651388+, RCR1548
S/N 656264+ & RCR1560 CAT 3 X 30 T40, DRVLN SLIP CLT 826-658C 28.
RCR1542 S/N 651387-, RCR1548
S/N 656263- & RCR1560 RPBY 826-658C 826-021C 28.
RCR1572 DRIVELINE 2300 X 38 W/CLUTCH 826-022C 28.
HHCS 1/2-13X3 1/2 GR8 802-265C 29.
NUT HEX NYLOCK 1/2-13 803-147C 30.
S/N ______+ CAT 3 X 30 T40, DRVLN SHEAR BL 826-659C 31.
RCR1542, RCR1548 & RCR1560
S/N ______- RPBY 826-659C 826-019C 31.
RCR1572 PTO 2300 X 38 SHEAR BOLT 826-020C 31.
HHCS 1/2-13X3 1/2 GR2 802-264C 32.
PIN DRAW 7/8 X 5 805-111C 33.
Not supplied PIN LYNCH 7/16 X 1 3/4 805-103C 34.
RCR1542 S/N 476454- RCR1548
S/N 476400- NUT WING 3/8-16 PLT 803-231C 35.
RCR1542 S/N 476454- RCR1548
S/N 476400- WASHER LOCK SPRING 3/8 PLT 804-013C 36.
RCR1542 S/N 476454- RCR1548
S/N 476400- WASHER FLAT 3/8 SAE PLT 804-012C 37.
RCR1542 S/N 476454- RCR1548
S/N 476400- ACCESS COVER PLATE 312-886D 38.
NUT HEX NYLOCK 5/8-11 PLT 803-148C 39.
MCCN ACCESS COVER 38-11 40.
As Required BLADE SPACER 16 GA .06 THICK 312-075D 41.
As Required BLADE SPACER 18 GA .05 THICK 312-082D 41.
As Required BLADE SPACER 20 GA .04 THICK 312-089D 41.
As Required BLADE SPACER 24 GA .03 THICK 312-808D 41.
RCR1542 BLADE BAR WELDMENT 312-680H 42.
Optional RCR1542 BLADE BAR SUB ASSY 312-679S 43.
(S/N 317416+) DRIVELINE HOOK HANGER W/HRDWR 800-320C 44.
RCR1542 S/N 476455+ RCR1548
S/N 476401+ PLUG LP 3" ID RUBBER 840-273C 45.
RCR1542 & RCR1548 S/N 546853+ HHCS 1/4-20X1 1/4 GR5 802-224C 46.
RCR1542 & RCR1548 S/N 546853+ MANUAL STORAGE CONTAINER 816-504C 47.
RCR1542 & RCR1548 S/N 546853+ WASHER FLAT 1/4 SAE PLT 804-007C 48.
RCR1542 & RCR1548 S/N 546853+ NUT HEX NYLOCK 1/4-20 803-255C 49.
RCR1542 MATCHED BLADE KIT 326-037A 50.
RCR1548 MATCHED BLADE KIT 326-038A 50.
NUT HEX FLANGE LOCK 5/8-11 PLT 803-263C 51.
16 RCR1542, RCR1548, RCR1560 & RCR1572 Rotary Cutter 312-556P 04/22/13
Table of Contents Part Number Index
Land Pride Section 2: Decks
Deck and Hitch (continued)
Applies to RCR1542, RCR1548, RCR1560, RCR1572
