141
Rotary Cutters Folding Deck
Specifications & Capacities
Designs, specifications, features and information are subject to change without notice.
RC5014 and RCM5014 Series
Min. PTO Horse Power
70
Gear Box Horsepower
250 HP Splitter
210 HP Center & wing
Gear Box
Lubrication & Capacity
Center deck & wings: 10 pints of Gear Lube 80-90W EP
Divider Gearbox: 5.5 pints of Gear Lube 80-90W EP
Cutting Capacity
Up To 3" Material
Machine Weight
7,282 lbs. Approx.
(With single row chain guards, 6 airplane tires, dual axle, 540 CV main driveline)
Blade Tip Speed
@ 540 RPM
@ 1000 RPM
Center blade: 17,377 FPM & Wing blade: 17,329 FPM
Center blade: 18,165 FPM & Wing blade:18,317 FPM
Tongue Weight
2300 lbs.
Hitch Types
Pull-Type, Self-Leveling Hitch & Clevis
Hitch Jack
Standard hand crank
Wing Offset
Right wing model with weight box on the left side
Cutting Width
Overall Width
Minimum Transport Width
13'-6"
14'-7"
8'-9"
Overall Length
19'-3"
Deck Height
10 1/2"
Cutting Height
2" to 14" High with hydraulic cylinder and stroke control spacers
Lift Hydraulics
4" x 8" hydraulic cylinder, hoses, fittings & stroke control spacers
Wing Hydraulics
3 1/2" x 12" hydraulic cylinder, hose & fittings
Wing Transport Protection
Wing transport lock
Deck Material Thickness
3/16"
Side Skirt Thickness
1/4"
Skid Shoes
Wing Deck
Center Deck
Reversible & replaceable
2 - Replaceable
Blades - 4 (2 per Carrier)
1/2" x 4" Thru-harden free swinging alloy steel with uplift
Blade Overlap
6"
Blade Bolt
Keyed with hardened flat washer & lock nut
Stump Jumper / Blade Holder
3/16" Round bolt-on stump-jumper with 1" diamond shaped blade bar
Deck Ring
Optional 1/2" x 3" fully welded
Front & Rear Guards
Optional rubber, single chain or double chain
Heavy Duty
Input Driveline Options
Conventional u-joint ASAE Category 5 with 1 3/8"-21 spline
Constant velocity u-joint ASAE Category 5 with 1 3/8"-21 spline or 1 3/4"-20 spline
Heavy Duty
Connecting Drivelines
ASAE Cat. 5 with slip-clutch
Wheel Options
6" x 21" Laminated tires
or 27" x 7.75" x 15" Used aircraft tires w/wo foam filling
or 15" Rims
Number of Wheels
5 - Wheel option: 4 on transport axle and one on wing axle
6 - Wheel option: 4 on transport axle and two on wing axle.
Transport Axle
Spring-cushioned on center transport axle
Hubs
Cast iron 5-bolt hubs with tapered roller bearings and with 1 3/4" shafts
Colors
Standard color: Beige
Optional colors: Green or Red
330-117S continue on next page
5/29/13
