Rotary Cutters, Folding Deck
Specifications & Capacities
Designs, specifications, features and information are subject to change without notice.
RCR3515 and RCRM3515 Models
RCR3515 & RCRM3515
Cutting Width
Overall Width
Minimum Transport Width 15’
15’-8”
8’
Cutting Height 2” - 14”
Overall Length 15’-1”
Deck Material Thickness 10 gauge
Deck Height 9”
Debris Guards Single Row Chain or Rubber
Hitch Type Pull, Self - Leveling Hitch & Clevis
Blades - 6 (2 per Carrier) 1/2” x 4” Heat Treated
Free Swinging Alloy Steel with Uplift
Blade Tip Speed (540 rpm = 15,268 fpm center & 15,000 fpm wings)
(1,000 rpm = 15,578 fpm center & 14,620 fpm wings)
Blade Holders Round Pan
Cutting Capacity 1 1/2”
PTO Drive Shafts 540 PTO: ASAE Category 4 {Input Shafts}
1000 PTO ASAE Category 4 {Output Shafts}
Connecting Drivelines Standard - Category 4 with Slip-Clutch
Optional - Category 5 with Slip-Clutch
Gear Boxes 540 RPM or 1000 RPM
160 HP Divider
110 HP Center & Wings
Wheel Options 6” x 21” Laminated or
15” Rims or
27”5 x 7.75” x 15” Used Aircraft Tires
Shock Load Suspension Springs on center axle
Machine Weight 3,780 lbs.
Tongue Weight 1300 lbs.
Min. PTO Horse Power 50
318-301S 9/09/08
