Powersure™ interactive rackmount, 2200 model, 1400 models – Liebert 700-2200 VA User Manual
Page 10
10
POWERSURE™ INTERACTIVE RACKMOUNT
2200 Model
1
3
4
6 2
3
6
1
5
5
5
700-1400 Models
*700 Model has detachable cord
1- Output
Receptacles
2- DB-9 Interface Port
3- AC
Inlet
4- Intellislot™ Communications Port
5- Circuit Protector or Fuse
6- Site Wiring Fault Indicator
On / Off
Alarm Silence
Load / Battery
Utility High / Low
Utility
R
On / Off Button
Alarm Silence /
Battery Test Button
Utility/ Battery
Status Indicator
Utility High / Low Indicator
Load / Battery
Level Indicators
Fault Indicator
