4.4.4.
Map Descriptor Examples
// Client Side Map Descriptors
Map_Descriptors
Map_Descriptor_Name,
Data_Array_Name,
Data_Array_Offset,
Function,
Node_Name,
Data_Type,
Object_ID,
Property,
Scan_Interval
CMD_AI_01,
DA_AI_01,
0,
RDBC,
BCU_01,
AI,
1,
Present_Value,
20.000s
CMD_AI_02,
DA_AI_01,
1,
RDBC,
BCU_01,
AI,
2,
Present_Value,
20.000s
CMD_AI_03,
DA_AI_01,
2,
RDBC,
BCU_01,
AI,
3,
Present_Value,
20.000s
CMD_AO_01,
DA_AO_01,
0,
RDBC,
BCU_01,
AO,
1,
Present_Value,
30.000s
CMD_AO_02,
DA_AO_01,
1,
RDBC,
BCU_01,
AO,
2,
Present_Value,
30.000s
CMD_AO_03,
DA_AO_01,
2,
RDBC,
BCU_01,
AO,
3,
Present_Value,
30.000s
Map_Descriptors
Map_Descriptor_Name,
Data_Array_Name,
Data_Array_Offset,
Function,
Node_Name,
Data_Type,
Object_ID,
Property,
Scan_Interval
CMD_DI_01,
DA_DI_01,
0,
RDBC,
BCU_01,
DI,
1,
Present_Value,
15.000s
CMD_DI_02,
DA_DI_01,
1,
RDBC,
BCU_01,
DI,
2,
Present_Value,
15.000s
CMD_DI_03,
DA_DI_01,
2,
RDBC,
BCU_01,
DI,
3,
Present_Value,
15.000s
CMD_DO_01,
DA_DO_01,
0,
RDBC,
BCU_01,
DO,
1,
Present_Value,
30.000s
CMD_DO_02,
DA_DO_01,
1,
RDBC,
BCU_01,
DO,
2,
Present_Value,
30.000s
CMD_DO_03,
DA_DO_01,
2,
RDBC,
BCU_01,
DO,
3,
Present_Value,
30.000s
