Example
// Client Side Connections
Connections
Adapter,
Protocol,
Poll_Delay
N1,
Bacnet_Eth,
0.500s
4.3.
Client Side Node Descriptors
Section Title
Nodes
Column Title
Function
Legal Values
Node_Name
Provide name for node
Up to 32 alphanumeric
characters
Node_ID
BACnet station address of physical
Server node
1-16777215
Protocol
Specify protocol used
Bacnet_Eth
Adapter
Specify port Adapter used
N1
Example
// Client Side Nodes
Nodes
Node_Name,
Node_ID,
Protocol,
Adapter
BCU_01,
1,
Bacnet_Eth,
N1
