FS-8704-02_BacnetEthernet.doc Driver Manual Page 11 of 20
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldServer.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: [email protected]
Example
// Server Side Connections
Connections
Adapter, Protocol
∗
N1, Bacnet_Eth
5.3. Server Side Node Descriptors
Section Title
Nodes
Column Title Function Legal Values
Node_Name Provide name for node
Up to 32 alphanumeric
characters
Node_ID
BACnet station address of physical
Server node
1-16777215
Protocol Specify protocol used Bacnet_Eth
Example
// Server Side Nodes
Nodes
Node_Name, Node_ID, Protocol
Virtual_BCU_11, 11, Bacnet_Eth
∗
Note that no connection information is necessary on Server side.
