PARTS LIST
KEY
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
5
PART #
7058908
6407508
6111002
6406602
6407802
6407302
6407202
6024702
6406401
6406501
6125101
6194601
6654521
6654121
3102909
3102922
3102904
3102910
3102501
3102601
3102802
3102502
6236701
3102804
6412001
6020601
3105401
3109602
6145801
3103101
6416601
3104301
6405201
QTY
1
1
1
1
1
2
1
1
4
2
2
6
1
1
4
1
2
1
10
4
3
2
4
1
3
2
6
2
6
2
3
1
6
DESCRIPTION
UPRIGHT FRAME
BENCH FRAME
HEIGHT ADJUSTMENT BAR
WOLFF SLEEVE
BASE LEG
SADDLE
LEG EXTENSION NECK
LEG EXTENSION
HINGE TAB
U-PIN
ROLLER PAD SHAFT
ROLLER PAD
SEAT PAD
BACK PAD
3/8 X 1” BOLT
3/8 X 2-3/4” BOLT
3/8 X 3” BOLT
1/2 X 3” BOLT
3/8” WASHER
3/8” LOCK WASHER
3/8” LOCK NUT
1/2” WASHER
1-3/4” SQ. END CAP
1/2” LOW HEIGHT LOCK NUT
3/8” SPRING PIN ASSEMBLY
1/2” FLANGE BEARING
3/4” STARLOCK COLLAR
PAL NUT
THUMBSCREW
1-1/4 X 5” GRIP
PARAGLIDE STRIP (8 ct.)
3/4” SQ. RUBBER BUMPER
2” SQ. END CAP
