Figure 5 – Life Fitness Parabody 807 User Manual
Page 10
10
FIGURE 5
13
STEP 5:
9
3/8 X 1” 15
20
4
0
1
2
3
4
5
6
1/2
1/2
1/2
1/2
1/2
1/2
• To assemble the SEAT PAD (13) to the WOLFF SLEEVE (4), start by sliding two HINGE TABS (9) over the PIN of the
WOLFF SLEEVE (ONE ON EACH SIDE) as shown in FIGURE 5, and SECURELY assemble each HINGE TAB (9) to the
SEAT PAD (13) using two 3/8 X 1” BOLTS (15), two 3/8” LOCK WASHERS (20), and two 3/8” WASHERS (19). (MAKE
SURE BOTH HINGE TABS ARE ALL THE WAY ON THE PIN)
19
