12
FIGURE 7
7
23
STEP 7:
12
0 1 2 3 4 5 6
1/2 1/2 1/2 1/2 1/2 1/2
• Insert one 1-3/4” SQ. END CAP (23) into the top of the LEG EXTENSION NECK (7) as shown in FIGURE 7.
• Slide two ROLLER PADS (12) over each end of the SHAFT of the LEG EXTENSION NECK (7), as shown in FIGURE 7, and
secure in place using two 3/4” STARLOCK COLLARS (27).
27
2
• Insert the LEG EXTENSION NECK (7) into the BENCH FRAME (2) and secure in place using on THUMBSCREW (29) as
shown in FIGURE 7.
29
