Linear DIGITAL TRANSMITTER GT-30 - Manual

Copyright © 2000 Linear Corporation 217130 A
1
2
3
REMOVE VISOR
CLIP AND SCREW
CAREFULLY REMOVE
CIRCUIT BOARD
INSTALL TWO
TYPE 2016 BATTERIES
PLUS (+) SIDE DOWN
REASSEMBLE
UNIT WHEN
FINISHED
GT-30
DIGITAL
TRANSMITTER
Operation Instructions
DESCRIPTION
Linear’s GT series of digital transmitters are wireless
radio controls designed for use with Genie Pro®
INTELLICODE™, Overhead Door® CodeDodger™, and
Linear® Model AM-RGR access control receivers. The
rolling-code GT radio format provides additional security
by changing the transmitter’s code with each use.
The GT-30 is a three-button transmitter that sends a
unique code for each button. Typically, one button is used
to operate a community access gate, another button can
activate the individual’s garage door, and a third button
can control an additional door or other device.
The transmitter is powered by two Type 2016 “coin cell”
batteries. A red indicator lights when the transmitter is
activated. A removable spring steel visor clip is supplied
attached to the back of the transmitter.
☞ NOTE: INTELLICODE™, CodeDodger™, Genie Pro®, and Overhead
Door® are registered trademarks of Overhead Door Corporation.
PROGRAM TRANSMITTER INTO RECEIVER
For INTELLICODE™ and CodeDodger™ systems, refer
to the instructions provided with the receiver to set it to a
“learning” mode. Activate the desired transmitter button
to program that button into the receiver
Linear’s Model AM-RGR receivers detect the signal from
the transmitter and pass its digital code to the AM/II
access controller.
GT-30 transmitters are manufactured and sold “Block
Coded” from the factory. Each block of transmitters is
labeled with the starting and ending block code number,
along with a facility code number. Refer to the AM/II
instructions for details on how to program the block and
facility code numbers into the controller.
(760) 438-7000 • FAX (760) 438-7043
USA & Canada (800) 421-1587 & (800) 392-0123
Toll Free FAX (800) 468-1340
www.linearcorp.com
REPLACING BATTERIES
When the red indicator on the face of the transmitter
lights dimly, or not at all during activation, the batteries
need replacing.
LINEAR LIMITED WARRANTY
This Linear product is warranted against defects in material and workmanship for twelve (12)
months. The Warranty Expiration Date is labeled on the product. This warranty extends only
to wholesale customers who buy direct from Linear or through Linear’s normal distribution
channels. Linear does not warrant this product to consumers. Consumers should inquire from
their selling dealer as to the nature of the dealer’s warranty, if any. There are no obligations or
liabilities on the part of Linear corporation for consequential damages arising out of or in
connection with use or performance of this product or other indirect damages with respect
to loss of property, revenue, or profi t, or cost of removal, installation, or reinstallation.
All implied warranties, including implied warranties for merchantability and implied warranties
for fi tness, are valid only until Warranty Expiration Date as labeled on the product. This Linear
Corporation Warranty is in lieu of all other warranties express or implied.
All products returned for warranty service require a Return Product Authorization Number (RPA#).
Contact Linear Technical Services at 1-800-421-1587 for an RPA# and other important details.
IMPORTANT !!!
Linear radio controls provide a reliable communications link and fi ll an important need in portable
wireless signaling. However, there are some limitations which must be observed.
• For U.S. installations only: The radios are required to comply with FCC Rules and Regulations as Part 15
devices. As such, they have limited transmitter power and therefore limited range.
• A receiver cannot respond to more than one transmitted signal at a time and may be blocked by radio
signals that occur on or near their operating frequencies, regardless of code settings.
• Changes or modifi cations to the device may void FCC compliance.
• Infrequently used radio links should be tested regularly to protect against undetected interference or fault.
• A general knowledge of radio and its vagaries should be gained prior to acting as a wholesale distributor
or dealer, and these facts should be communicated to the ultimate users.
• This device complies with FCC Part 15. Operation is subject to the following two conditions: (1) This device
may not cause harmful interference and (2) this device must accept any interference received, including
interference that may cause undesired operation.
217130A.INDD 06/06/00, 8:51 AM 1
