Linear LMT-1 User Manual

Lmt-1 portable transmitter instruction manual

LINEAR LIMITED WARRANTY

This Linear product is warranted against defects in material and
workmanship for twelve (12) months. The Warranty Expiration
Date is labeled on the product. This warranty extends only to
wholesale customers who buy direct from Linear or through
Linear’s normal distribution channels. Linear does not warrant
this product to consumers. Consumers should inquire from
their selling dealer as to the nature of the dealer’s warranty, if any.
There are no obligations or liabilities on the part of Linear
Corporation for consequential damages arising out of or in
connection with use or performance of this product or other
indirect damages with respect to loss of property, revenue,
or profit, or cost of removal, installation, or reinstallation. All
i m p l i e d w a r r a n t i e s , in cl ud in g i mp li ed war r a nt ie s f or
merchantability and implied warranties for fitness, are valid only
until Warranty Expiration Date as labeled on the product. This
Linear Corporation Warranty is in lieu of all other warranties
express or implied.
For warranty service on Linear equipment return product, at
sender’s expense to:
Linear Service Center
2580 Pioneer Avenue, Suite C
Vista, CA 92083

IMPORTANT !!!

Linear radio controls provide a reliable communications link and fill an
important need in portable wireless signaling. However, there are some
limitations which must be observed.

✶

For U.S. installations only: The radios are required to comply with FCC Rules
and Regulations as Part 15 devices. As such, they have limited transmitter
power and therefore limited range.

✶

A receiver cannot respond to more than one transmitted signal at a time and
may be blocked by radio signals that occur on or near their operating
frequencies, regardless of code settings.

✶

Changes or modifications to the device may void FCC compliance.

✶

Infrequently used radio links should be tested regularly to protect against
undetected interference or fault.

✶

A general knowledge of radio and its vagaries should be gained prior to acting
as a wholesale distributor or dealer, and these facts should be communicated
to the ultimate users.

✶

This device complies with FCC Rules Part 15. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference
and (2) this device must accept any interference that may be received,
including interference that may cause undesired operation.

208378 A

LMT-1
Portable
Transmitter

Instruction Manual

(619) 438-7000

•

FAX (619) 438-7043

USA & Canada (800) 421-1587 & (800) 392-0123

Toll Free FAX (800) 468-1340

INTRODUCTION

The LMT-1 is a compact, light-weight, wireless transmitter. When
activated by pressing the button for two seconds, it will trigger the
remote receiver programmed to recognize the transmitter.
The unit can be used on a key ring or worn suspended from a
neck chain. A neck chain is packaged with the LMT-1.
The LMT-1 incorporates Linear’s proprietary “MegaCode” circuit
that provides each transmitter with over one million security
codes.
A Duracell MN21 battery powers the transmitter. The red LED on
the front of the transmitter will light when the unit is activated.

TRANSMITTER CODING

Each LMT-1 transmitter has been pre-programmed at the factory
to one in a million codes. The transmitter will retain its
pre-programmed code even with low or no batteries.
Refer to the receiver’s instructions for details on programming the
transmitter into the receiver. Most receivers have a “learning” or
“program” mode. Triggering the transmitter with the receiver in a
“learning” mode will cause the transmitter’s code to be entered
into the receiver’s memory.
