Chapter 7 Port Redundancy
32 Cajun M770 Manager User’s Guide
Adding a Port Redundancy
To designate a port redundancy connection:
1 In the Port Redundancy dialog box, enter a name for the redundancy in the
Redundancy Name field. For example,
Redund1 .
Note: The name for a redundancy may not contain any spaces.
2 Select a primary port from the Primary field.
3 Select a secondary port from the Secondary field.
4 Click Add.
The new port redundancy is added to the list of existing port redundancies.
To close the Port Redundancy dialog box, click Cancel.
Note: Ports that have already been designated in one redundancy scheme, may not
be selected for another one.
Editing a Port Redundancy
To edit an existing redundancy connection:
1
In the Port Redundancy dialog box, click on the redundancy connection you
wish to edit. The connection information appears in the boxes at the bottom of
the Port Redundancy window.
2 Change the information as desired.
3 Click Update.
The current port redundancy in the list is updated according to the modifications
made.
Deleting a Port Redundancy
To delete a port redundancy connection:
1
In the Port Redundancy dialog box, click on the redundancy connection you
wish to delete.
2 Click Delete.
The port redundancy is deleted from the list.
