COMPONENTS LIST
ITEM NO.
QTY.
PART NO.
DESCRIPTION
1
1
8188301
FRONT UPRIGHT ASSEMBLY
2
1
8210501
FOOT PLATE WITH MATS ASSEMBLY
4
1
8349801
RIGHT UPRIGHT ASSEMBLY
5
1
8349901
LEFT UPRIGHT ASSEMBLY
6
2
8264701
GUIDE ROD ASSEMBLY
8
1
8317801
FRONT SHROUD ASSEMBLY
9
1
8317701
MOUNTING BRACKET
11
2
8264801
FLOATING PULLEYS ASSEMBLY
12
1
8262501
TOP PLATE ASSEMBLY
13
1
8344601
RIGHT BOTTOM PLATE ASSEMBLY
14
1
7963701
SELECTOR PIN, 80/20, ASSEMBLY
15
1
8288301
MAIN TOP COVER WITH INSERTS ASSEMBLY
16
1
8235801
TOP BACK COVER
17
1
8235701
TOP FRONT COVER
22
2
8264701
GUIDE ROD
23
2
8264301
WEIGHT STACK CUSHION
25
1
8349701 UPPER
SWIVEL PULLEYS
ASSEMBLY
8350601
UPPER RIGHT PULLEY ASSEMBLY
8350701
UPPER LEFT PULLEY ASSEMBLY
26
1
8350301
LOWER LEFT PULLEY ASSEMBLY
27
1
8350201
LOWER RIGHT PULLEY ASSEMBLY
28
1
8364401
SIDE TOP LEFT COVER
29
1
8364501
SIDE TOP RIGHT COVER
30
1
8344501
LEFT BOTTOM PLATE
32
1
7777301
TOUCH UP PAINT, PLT
36
2
7642301
BUMPER, CM/MJ, PLUG
37
6
7672601
QUICK CONNECT
38
2
8140701
SHORT HANDLE ASSEMBLY
39
2
8140702
MEDIUM HANDLE ASSEMBLY
40
2
8140703
LONG HANDLE ASSEMBLY
41
1
7745801
FOOT STRAP
42
2
8286101
GUIDE CABLE
43
1
8285902
UPPER CABLE (LONG) ASSEMBLY
44
2
8285901
LOWER CABLE (SHORT) ASSEMBLY
45
1
8289201
USERS GUIDE
46
15
7935301
WEIGHT PLATE, 10LB, CASTEEL
48
1
745201
WALL CHART
49
1
8289001
DVD
50
1
8259201
BACK THIGH HOLD CLAMP
51
1
8259101
FRONT THIGH HOLD CLAMP
52
1
8263001
THIGH HOLD TUBE
53
2
7424701
SHORT ROLLER PAD
54
1
8263701
TULIP STYLE KNOB
55
1
8350001
RIGHT SUPPORT LEG
56
1
8350101
LEFT SUPPORT LEG
Accessory Bar (Qty 1)
8288001
Adapter Rings (Qty 2)
7944401
WEIGHT STACK LABELS (Qty. 1)
8327001
8264702
(Assembly)
8289101
7745501
