POWER FEED 10
A-1 INSTALLATION A-1
TECHNICAL SPECIFICATIONS – Power Feed 10 Wire Drive & Control Box
WIRE DRIVE OR WIRE DRIVE SECTION OF FEEDER
SPEC.# TYPE LOW SPEED RATIO HIGH SPEED RATIO
* Also part of K1538-[ ] Boom package and K1541-[ ] Bench Feeder.
Δ Dimensions do not include wire reel.
# For Control Box and wire drive dimensions and weights, see individual component listings.
Wire Size Wire Size
Low Speed Solid Cored High Speed Solid Cored
K1540-1 Power Feed 10 50-800 IPM .025 - 3/32 in. .035 - .125 in 75 - 1200 IPM .025 - 1/16 in. .035 - 5/64 in.
K1540-2 Wire Drive (1.27-20.3 m/m) (0.6 - 2.4 mm) (0.9 - 3.2 mm) (2.03 - 30.5 m/m) (0.6 - 1.6 mm) (0.9 - 2.0 mm)
K1538-1, Power Feed 10 50-800 IPM .025 - 3/32 in. .035 - .125 in 75 - 1200 IPM .025 - 1/16 in. .035 - 5/64 in.
-2,-3,-4, Boom Package# (1.27-20.3 m/m) (0.6 - 2.4 mm) (0.9 - 3.2 mm) (2.03 - 30.5 m/m) (0.6 - 1.6 mm) (0.9 - 2.0 mm)
-5,-6
K1541-1 Power Feed 10 50-800 IPM .025 - 3/32 in. .035 - .125 in 75 - 1200 IPM .025 - 1/16 in. .035 - 5/64 in.
K1541-2 Bench Model (1.27-20.3 m/m) (0.6 - 2.4 mm) (0.9 - 3.2 mm) (2.03 - 30.5 m/m) (0.6 - 1.6 mm) (0.9 - 2.0 mm)
Drive and
Control Box
CONTROL BOX, WIRE DRIVE AND COMPLETE UNITS
SPEC.# TYPE INPUT POWER PHYSICAL SIZE• TEMPERATURE RATING
Dimensions
Height Width Depth Weight Operating Storage
K1539-1,-2 Power 40 VDC 13.0 ” 8.50 ” 4.0 ” 8.5 Lbs
(Control Feed 10 (330 mm) ( 215 mm) (105 mm) (3.8 Kg)
Box Control
Only)* Box
K1540-1,-2 Power 40 VDC 7.6 ” 12.9 ” 13.7 ” 30 Lbs
(Wire Feed 10 (195 mm) (325 mm) (345 mm) (13.6 Kg)
Drive Wire
Only)* Drive
+40°C +40°C
to to
K1541-1,-2 Power 40 VDC 18.5 ” 13.5 ” 30.5 ” 62 Lbs -20°C -40°C
Bench Feed 10 ( 470 mm) (345 mm) (775 mm) (28.1 Kg.)
Model Bench Model
FeederΔ Drive and
Control Box
