Specifications
1 And 1-
1
/
2
Ton Systems
60 HZ
50 HZ
AIR COOLED SYSTEM
with Outdoor Condensing Unit
with Centrifugal Condensing Unit
with Outdoor Condensing Unit with Centrifugal Condensing Unit
Split System
Self-Contained
Split System
Self-Contained
1 Ton
1.5 Tons
1 Ton
1.5 Tons
1 Ton
1.5 Tons
1 Ton
1.5 Tons
Evaporator
MMD12E
MMD18E
MMD12A
MMD18A
MMD11E
MMD17E
MMD11A
MMD17A
Condensing Unit
PFH014A
PFH020A
MM2CF
MM2CF
PFH013A
PFH019A
MM2CF
MM2CF
Net Capacity Data*BTUH (kW) High Fan Speed
80 F (27.7) DB
Total
14,100 (4.1)
19,800 (5.8)
13,300 (3.9)
19,300 (5.7)
14,400 (4.2)
21,200 (4.2)
13,400 (3.9)
20,800 (6.1)
50% RH
Sensible
11,600 (3.4)
15,500 (4.5)
11,300 (3.3)
15,300 (4.5)
11,700 (3.4)
16,000 (4.7)
11,300 (3.3)
15,900 (4.7)
75 F (23.9 C) DB
Total
13,000 (3.8)
18,400 (5.4)
12,300 (3.6)
18,000 (5.3)
13,300 (3.9)
19,800 (5.8)
12,400 (3.6)
19,500 (5.7)
50% RH
Sensible
11,200 (3.3)
15,000 (4.4)
10,900 (3.2)
14,900 (4.4)
11,300 (3.3)
15,600 (4.6)
10,900 (3.2)
15,500 (4.5)
72 F (22.2 C) DB
Total
12,400 (3.6)
17,700 (5.2)
11,800 (3.5)
17,300 (5.1)
12,700 (3.7)
19,000 (5.6)
11,900 (3.5)
18,700 (5.5)
50% RH
Sensible
10,900 (3.2)
14,800 (4.3)
10,600 (3.1)
14,600 (4.3)
11,000 (3.2)
15,300 (4.5)
10,700 (3.1)
15,200 (4.5)
Net Capacity Data*BTUH (kW) Low Fan Speed
80 F (26.7) DB
Total
14,000 (4.1)
19,300 (5.7)
13,300 (3.9)
18,800 (5.5)
14,300 (4.2)
20,600 (6.0)
13,400 (3.9)
20,300 (5.9)
50% RH
Sensible
10,500 (3.1)
13,800 (4.0)
10,200 (3.0)
13,700 (4.0)
10,600 (3.1)
14,400 (4.2)
10,200 (3.0)
14,200 (4.2)
75 F (23.9 C) DB
Total
12,900 (3.8)
18,000 (5.3)
12,300 (3.6)
17,700 (5.2)
13,200 (3.9)
19,200 (5.6)
12,400 (3.6)
18,900 (5.5)
50% RH
Sensible
10,100 (3.0)
13,500 (4.0)
9,900 (2.9)
13,400 (3.9)
10,200 (3.0)
14,000 (4.1)
9,900 (2.9)
13,900 (4.1)
72 F (22.2) DB
Total
12,300 (3.6)
17,200 (5.0)
11,800 (3.5)
16,900 (5.0)
12,600 (3.7)
18,400 (5.4)
11,900 (3.5)
18,200 (5.3)
50% RH
Sensible
9,900 (2.9)
13,300 (3.9)
9,700 (2.8)
13,100 (3.8)
10,000 (2.9)
13,800 (4.0)
9,700 (2.8)
14,200 (4.2)
60 HZ 50 HZ
WATER COOLED
GLYCOL COOLED
WATER COOLED
GLYCOL COOLED
Self-Contained
Self-Contained
Self-Contained
Self-Contained
1 Ton
1.5 Tons
1 Ton
1.5 Tons
1 Ton
1.5 Tons
1 Ton
1.5 Tons
Evaporator
MMD14W
MMD20W
MMD14W
MMD20W
MMD13W
MMD19W
MMD13W
MMD19W
Net Capacity Data*BTUH (kW) High Fan Speed
80F (26.7) DB
Total
15,000 (4.4)
22,000 (6.4)
13,700 (4.0)
19,900 (5.8)
15,000 (4.4)
23,000 (6.7)
13,900 (4.1)
21,300 (6.2)
50% RH
Sensible
12,500 (3.7)
16,600 (4.9)
12,000 (3.5)
15,800 (4.6)
12,400 (3.6)
15,500 (4.5)
12,000 (3.5)
16,400 (4.8)
75 F (23.9 C) DB
Total
13,900 (4.1)
20,500 (6.0)
12,800 (3.8)
18,600 (5.4)
13,900 (4.1)
21,300 (6.2)
12,900 (3.8)
20,000 (5.9)
50% RH
Sensible
12,000 (3.5)
16,100 (4.7)
11,600 (3.4)
15,400 (4.5)
12,000 (3.5)
15,100 (4.4)
11,600 (3.4)
15,900 (4.7)
72 F (22.2 C) DB
Total
13,300 (3.9)
19,600 (5.7)
12,300 (3.6)
17,900 (5.2)
13,300 (3.9)
20,400 (5.6)
12,400 (3.6)
19,200 (5.6)
50% RH
Sensible
11,800 (3.5)
15,800 (4.6)
11,400 (3.3)
15,100 (4.4)
11,800 (3.5)
14,900 (4.4)
11,400 (3.3)
15,700 (4.6)
Net Capacity Data*BTUH (kW) Low Fan Speed
80 F (26.7) DB
Total
14,600 (4.3)
21,100 (6.2)
13,400 (3.9)
18,900 (5.5)
14,500 (4.2)
23,900 (7.0)
13,500 (4.0)
20,700 (6.1)
50% RH
Sensible
11,000 (3.2)
14,800 (4.3)
10,500 (3.1)
13,900 (4.1)
11,000 (3.2)
17,300 (5.1)
10,600 (3.1)
14,600 (4.3)
75 F (23.9 C) DB
Total
13,500 (4.0)
19,700 (5.8)
12,500 (3.7)
17,800 (5.2)
13,500 (4.0)
22,200 (6.5)
12,600 (3.7)
19,300 (5.7)
50% RH
Sensible
10,700 (3.1)
14,400 (4.2)
10,200 (3.0)
13,600 (4.0)
10,600 (3.1)
16,900 (5.0)
10,300 (3.0)
14,300 (4.2)
72 F (22.2 C) DB
Total
12,900 (3.8)
18,900 (5.5)
12,000 (3.5)
17,100 (5.0)
12,900 (3.8)
21,200 (6.2)
12,100 (3.5)
18,600 (5.4)
50% RH
Sensible
10,400 (3.0)
14,200 (4.2)
10,000 (2.9)
13,400 (3.9)
10,400 (3.0)
16,500 (4.8)
10,100 (3.0)
14,000 (4.1)
60 HZ
50 HZ
CHILLED WATER
Self-Contained
Self-Contained
1.5 Tons
1.5 Tons
Evaporator
MMD23C
MMD22C
Capacity Data BTUH (kW) High Fan Speed
80 F (26.7) DB
Total
21,800 (6.4)
21,800 (6.4)
50% RH
Sensible
16,000 (4.7)
16,000 (4.7)
75 F (23.9 C) DB
Total
14,300 (4.2)
14,300 (4.2)
50% RH
Sensible
13,100 (3.8)
13,100 (3.8)
72 F (22.2 C) DB
Total
11,000 (3.2)
11,000 (3.2)
50% RH
Sensible
11,000 (3.2)
11,000 (3.2)
Capacity Data BTUH (kW) Low Fan Speed
80 F (26.7) DB
Total
17,100 (5.2)
17,100 (5.2)
50% RH
Sensible
12,800 (3.7)
12,800 (3.7)
75 F (23.9 C) DB
Total
11,300 (3.1)
11,300 (3.1)
50% RH
Sensible
10,300 (3.0)
10,300 (3.0)
72 F (22.2 C) DB
Total
8,500 (2.5)
8,500 (2.5)
50% RH
Sensible
8,500 (2.5)
8,500 (2.5)
*The net capacity data has fan motor heat factored in for all ratings and the entering air condition of 72˚F (22.2˚C), 50% RH is the standard rating condition of ASHRAE 127-2001
