Liebert Overhead Precision Cooling and Humidity Control Mini-Mate2 - Manual (Page 11)

60 Hz 50 Hz
AIR COOLED SYSTEM
w/Outdoor Condensing Unit w/Centrifugal Condensing Unit w/Outdoor Condensing Unit w/Centrifugal Condensing Unit
5 Tons 5 Tons 5 Tons 5 Tons
Evaporator MMD60E MMD60E MMD59E MMD59E
Condensing Unit PFH067A MCD65A PFH066A MCD64A
Net Capacity Data*-BTUH (kW)
80 F (26.7 C) DB
Total 65,000 (19.0) 66,200 (19.4) 65,400 (19.2) 65,500 (19.2)
50% RH Sensible 54,400 (15.9) 54,800 (16.1) 54,800 (16.1) 54,800 (16.1)
75 F (23.9 C) DB Total 60,500 (17.7) 61,800 (18.1) 60,000 (17.6) 61,000 (17.9)
50% RH Sensible 52,600 (15.4) 53,100 (15.6) 52,600 (15.4) 53,000 (15.5)
72 F (22.2 C) DB Total 58,100 (17.0) 59,400 (17.4) 57,200 (16.8) 58,600 (17.2)
50% RH Sensible 51,500 (15.1) 52,100 (15.3) 51,300 (15.0) 51,900 (15.2)
WATER COOLED GLYCOL COOLED CHILLED WATER WATER COOLED GLYCOL COOLED CHILLED WATER
5 Tons 5 Tons 5 Tons 5 Tons 5 Tons 5 Tons
Evaporator MMD60E MMD60E MMD92C MMD59E MMD59E MMD91C
Condensing Unit MCD69W MCD69W MCD68W MCD68W
Net Capacity Data*-BTUH (kW)
80 F (26.7 C) DB
Total 70,800 (20.7) 63,400 (18.6) 94,000 (27.5) 70,000 (20.5) 62,000 (18.2) 94,000 (27.5)
50% RH Sensible 56,900 (16.7) 54,200 (15.9) 64,000 (18.8) 56,600 (16.6) 53,700 (15.7) 64,000 (18.8)
75 F (23.9 C) DB Total 66,100 (19.4) 59,300 (17.4) 62,900 (18.4) 65,100 (19.1) 57,900 (17.0) 62,900 (18.4)
50% RH Sensible 55,200 (16.2) 52,500 (15.4) 53,300 (15.6) 54,800 (16.1) 51,900 (15.2) 53,300 (15.6)
72 F (22.2 C) DB Total 63,300 (18.5) 57,000 (16.7) 51,300 (15.0) 62,200 (18.2) 55,700 (16.3) 51,300 (15.0)
50% RH Sensible 54,100 (15.9) 51,400 (15.1) 48,300 (14.2) 53,600 (15.7) 50,900 (14.9) 48,300 (14.2)
60 Hz 50 Hz
AIR COOLED SYSTEM
w/Outdoor Condensing Unit w/Centrifugal Condensing Unit w/Outdoor Condensing Unit w/Centrifugal Condensing Unit
8 Tons 8 Tons 8 Tons 8 Tons
Evaporator MMD96E MMD96E MMD95E MMD95E
Condensing Unit PFH096A MCD96A PFH095A MCD95A
Net Capacity Data*-BTUH (kW)
80 F (26.7 C) DB
Total 100,200 (29.4) 95,900 (28.1) 96,700 (28.3) 93,800 (27.5)
50% RH Sensible 80,500 (23.6) 79,400 (23.3) 79,300 (23.2) 78,300 (22.9)
75 F (23.9 C) DB Total 93,100 (27.3) 89,500 (26.2) 90,200 (26.4) 87,400 (25.6)
50% RH Sensible 78,600 (23.0) 77,000 (22.6) 77,400 (22.7) 76,200 (22.3)
72 F (22.2 C) DB Total 89,200 (26.1) 86,800 (25.4) 86,200 (25.3) 83,600 (24.5)
50% RH Sensible 77,200 (22.6) 76,500 (22.4) 75,900 (22.2) 74,900 (21.9)
WATER COOLED GLYCOL COOLED CHILLED WATER WATER COOLED GLYCOL COOLED CHILLED WATER
8 Tons 8 Tons 8 Tons 8 Tons 8 Tons 8 Tons
Evaporator MMD96E MMD96E MMD8TC MMD95E MMD95E MMD8TC
Condensing Unit MCD98W MCD98W MCD97W MCD97W
Net Capacity Data*-BTUH (kW)
80 F (26.7 C) DB
Total 105,000 (30.8) 93,000 (27.2) 145,600 (42.7) 101,100 (29.6) 89,600 (26.3) 145,600 (42.7)
50% RH Sensible 83,300 (24.4) 77,500 (22.7) 98,300 (28.8) 81,000 (23.7) 76,500 (22.4) 98,300 (28.8)
75 F (23.9 C) DB Total 97,400 (28.5) 86,400 (25.3) 96,900 (28.4) 93,600 (27.4) 84,500 (24.8) 96,900 (28.4)
50% RH Sensible 81,300 (23.8) 75,000 (22.0) 81,400 (23.8) 78,700 (23.1) 75,600 (22.2) 81,400 (23.8)
72 F (22.2 C) DB Total 93,200 (27.3) 84,100 (24.6) 80,200 (23.5) 89,400 (26.2) 81,100 (23.8) 80,200 (23.5)
50% RH Sensible 79,000 (23.1) 75,300 (22.1) 74,300 (21.8) 77,100 (22.6) 73,900 (21.7) 74,300 (21.8)
11 11
Specifications
5 And 8 Ton Split Systems
*The net capacity data has fan motor heat factored in for all ratings and the entering air condition of 72˚F (22.2˚C), 50% RH is the standard rating condition of ASHRAE 127-2001
