1
Hardware
DEFINITY ProLogix Solutions Release 2 Overview 555-235-100
Issue 2 June 1999 1-10
The compact modular cabinet weighs 50 to 60 lbs. and has the following dimensions:
•
height: 24.5 inches (62.2 cm)
•
width: 25.5 inches (64.8 cm)
•
depth: 11.3 inches (28.7 cm)
The R7csi has the following characteristics:
•
It uses the compact modular cabinet (CMC).
•
Each CMC has its own power supply.
•
Up to three cabinets can be connected together in a single-port network.
•
It enables small organizations to expand while keeping the initial investment
moderate.
•
It is mounted on a wall. However, it can be mounted on a table or floor as long as
only one cabinet is required. For approved mounting configurations, refer to the
Installation and Maintenance guide on the Library CD.
•
It contains 10 universal port slots.
•
The first two universal port slots in the first cabinet are typically used for the
TN798B processor and the TN2182B Tone-Clock. (However, these slots are not
dedicated to the processor and Tone-Clock.)
