14 Chapter 4: Connecting the Router
Placement Options
Wall-Mount Option
The Router has four wall-mount slots on its bottom panel. The distance between two adjacent slots is
62 mm (2.44 inches).
Before you begin, make sure you have four screws that are size #4—this indicates a diameter
measurement of 0.112 inches (2.845 mm).
1. Determine where you want to mount the Router.
2. Drill four holes into the wall. Make sure adjacent holes are 62 mm (2.44 inches) apart.
3. Insert a screw into each hole, and leave 5 mm (0.2 inches) of its head exposed.
4. Maneuver the Router so the wall-mount slots line up with the four screws.
5. Place the wall-mount slots over the screws and slide the Router down until the screws fit snugly
into the wall-mount slots.
Proceed to “Chapter 5: Configuring the Router.”
Figure 4-10: Measurement between
Wall-Mount Slots
62 mm
(2.44 inches)
