LevelOne OfficeCon GSW-0440T - Manual (Page 20)

20
Model GSW-0840T
Standards
IEEE 802.3: 10BASE-T
IEEE 802.3u: 100BASE-TX
IEEE 802.3ab: 1000BASE-T
IEEE 802.3x: Flow-Control support
Ports Eight (8) 1000BASE-T/100BASE-TX/10BASE-T TP Copper Ports
Media Support 10BASE-T: Category 3, 4 or 5 TP
1000BASE-TX/1000BASE-T: Category 5 TP
Bandwidth 1000BASE-T 2000/1000/200/100/20/10 Mbps
Forwarding/Filtering Rate 1488000 packets/second per port @ 1000Mbps maximum
148800 packets/second per port @ 100Mbps maximum
14880 packets/second per port @ 10Mbps maximum
Latency 2.2 µsec @1000Mbps minimum
11 µsec @100Mbps minimum
75 µsec @ 10Mbps minimum
MAC Addresses 8K Self-Learning
Configuration Utility Console port
Buffer Memory 256K Bytes Packet Memory
Duplex Modes Auto-Negotiation
Crossover All ports have Auto-Crossover function
Switch One (1) for Power
LED Indicators One (1) per port for display Link/ACT
One (1) per port for display speed- 1000Mbps(Green)
One (1) per port for display 100Mbps(Green) or 10Mbps(Off)
One (1) per port for display Full-duplex and Half –Duplex (collision)
Power Supply Full range Auto-Switching
Input voltage: 100 ~ 240 +-10% VAC/ 50 ~ 60Hz
Power Consumption 30 W maximum
Environment Operating Temperature: 0 ° ~ 45°C (32° ~ 113°F)
Storage Temperature: 0 ° ~ 70°C
Humidity: 10% ~ 90% Non-Condensing
Dimensions 265x185x44mm (10.4x7.3x1.7inches)
