10: Maintenance and Diagnostics Settings
EDS Device Servers User Guide
97
Filesystem Browser Page
Filesystem
Browser Page
Settings
Description
Create
File
Enter the name of the file you want to create, and then click
Create.
Directory
Enter the name of the directory you want to create, and then
click Create.
Upload File
Enter the path and name of the file you want to upload via
HTTP or use the Browse button to select the file, and then
click Upload.
Copy File
Source
Enter the location where the file you want to copy resides.
Destination
Enter the location where you want the file copied. After you
specify a source and destination, click Copy to copy the file.
Move
Source
Enter the location where the file you want to move resides.
Destination
Enter the location where you want the file moved. After you
specify a source and destination, click Move to move the file.
TFTP
Action
Select the action that is to be performed via TFTP. Choices
are:
Get = a “get” command will be executed to store a file locally.
Put = a “put” command will be executed to send a file to a
remote location.
Mode
Select a TFTP mode to use. Choices are:
ASCII
Binary
Local File
Enter the name of the local file on which the specified “get” or
“put” action is to be performed.
Remote File
Enter the name of the file at the remote location that is to be
stored locally (“get’) or externally (“put”).
Host
Enter the IP address or name of the host involved in this
operation.
Port
Enter the number of the port involved in TFTP operations. Click
Transfer to complete the TFTP transfer.
