Footprint dimensions – Liebert Challenger ITR User Manual
Page 51
Split System Models
45
Figure 21 Outdoor air-cooled condensing unit—top air discharge models
SL-11081PG 5
C
A
2 "
B
LEFT
AIR
INTAKE
(51mm)
D
GUARD
HEIGHT
TOP
AIR
DISCHARGE
RIGHT
AIR
INTAKE
SHADED AREA
INDICATES A RECOMMENDED
CLEARANCE OF 18" (457mm)
FOR PROPER AIR FLOW
SHADED AREA
INDICATES A RECOMMENDED
CLEARANCE OF 24" (610mm)
FOR COMPONENT ACCESS
AND REMOVAL.
SHADED AREA
INDICATES A RECOMMENDED
CLEARANCE OF 18" (457mm)
FOR PROPER AIR FLOW
REMOVABLE FRONT PANEL FOR
ACCESS TO HIGH VOLTAGE &
LOW VOTLAGE CONNECTIONS,
AND REFRIGERATION COMPONENTS.
36 1/8 "
4 23/32 "
25 3/32 "
46 7/32 "
53 3/16 "
4 " TYP.
32 1/8 "
2 " TYP.
2 "
2 "
(918mm)
(102mm)
(51mm)
(1351mm)
(120mm)
(637mm)
(1174mm)
(51mm)
(51mm)
(816mm)
FOOTPRINT
DIMENSIONS
1/2" Bolt-Down Holes
(6 places)
SL-11081 PG 7
* System 2 (23 & 33kW)
Electrical Entrance for
High Voltage Connection
Electrical Entrance
for Low Voltage
Connection
Liquid Line
Quick Connect
(Male Coupling)
Suction Line
Quick Connect
(Male Coupling)
* System 1 (3 Ton)
* System 1 and System 2 on
8 Ton
only.
G
F
B
C
A
D
E
UNIT DIMENSIONS
PIPING & ELECTRICAL
CONNECTIONS
(see Table 27)
