25 Chapter 6: Configuring the PrintServer Using the Web-based Utility
The Printer Tab - Logical Port
Wireless-G PrintServer for USB 2.0
The Printer Tab - Logical Port
The Logical Printers tab contains the logical printer settings of the PrintServer. Configure them for each Logical
Printer. (See Figure 6-10.)
The PrintServer has six logical or virtual printer ports. For example, you can have three different configurations
for your parallel printer: Logical Printer 1 for landscape orientation, Logical Printer 2 for double-sided copies, and
Logical Printer 3 for manual feed. Then you will map Logical Printers 1, 2, and 3 to the physical printer on the
PrintServer’s Parallel port.
Select Printer. From the Logical Printer Port No: drop-down menu, select the number (1-6) of the printer you
wish to configure. From the Port drop-down menu, select the PrintServer’s physical port, Parallel 1 or USB 1.
Click the Get Data button to update the display with the current data for the selected logical printer.
Details
• Pre-string (Hex). Enter the printer control string (in hexadecimal characters) to be sent to the printer before
each print job. This string cannot exceed 30 characters.
• Post String (Hex). Enter the printer control string (in hexadecimal characters) to be sent to the printer after
each print job. This string cannot exceed 30 characters.
• Convert LF to CR+LF. If checked, LF (line feed) characters are changed to CR+LF (carriage return + line
feed).
Click the Save button to apply your changes, or click Cancel to cancel your changes.
Figure 6-10: Printer - Logical Port
