HDMI Connection
RS-232C IN
(SERVICE ONLY)
A
(
RGB(PC) IN
SERVICE
ONLY
HDMI/DVI IN
HDMI-DVD OUTPUT
1
19/22LG3**
RGB IN
COMPON
RGB(PC)
1
2
VIDEO
Y P B
HDMI/DVI IN
2
1
HDMI-DVD OUTPUT
1
26LG3**
Connect the HDMI output of the DVD to the H HD DM MII//D DVVII IIN N or H HD DM MII//D DVVII IIN N 1 1//2 2//3 3 jack on the TV.
No separated audio connection is necessary.
HDMI supports both audio and video.
1. How to connect
2. How to use
■ Select the H HD DM MII or H HD DM MII1 1//2 2//3 3 input source on the TV using the IIN NPPU UT T button on the remote control.
■ Refer to the DVD player's manual for operating instructions.
2
1
