TROUBLESHOOTING & REPAIR
F-53
F-53
IDEALARC CV-400
RETEST AFTER REPAIR
Retest a machine:
• If it is rejected under test for any reason that requires you to remove any mechanical part which could affect the
machine’s electrical characteristics. OR
• If you repair or replace any electrical components.
INPUT IDLE AMPS AND WATTS
Input Volts/Phase/Hertz
Maximum Idle Amps
Maximum Idle KW
200/3/60
10.9
1.2
208/3/60
10.5
1.2
220/3/60
9.9
1.2
230/3/60
9.5
1.2
380/3/60
5.8
1.2
400/3/60
5.5
1.2
415/3/60
5.3
1.2
440/3/60
5.0
1.2
460/3/60
4.8
1.2
500/3/60
4.4
1.2
575/3/60
3.8
1.2
200/3/50
19.8
1.2
220/3/50
18.0
1.2
230/3/50
17.2
1.2
380/3/50
10.4
1.2
400/3/50
9.9
1.2
415/3/50
9.5
1.2
440/3/50
9.0
1.2
500/3/50
7.9
1.2
OPEN CIRCUIT VOLTAGES
Test Points
Input Hertz
Open Circuit Volts
Welding Output Terminals
60
43/47VDC
Welding Ouput Terminals
50
43/47VDC
Auxiliary Output (#31 - #32)
60
114/124VAC
Auxiliary Output (#31 - #32)
50
109/119VAC
Auxiliary Output (#41 - #42)
60
43.8/47.5VAC
Auxiliary Output (#41 - #42)
50
42.0/45.6VAC
Auxiliary Output (#51 - #52)
50
220/231VAC
WELDING OUTPUT LOAD TEST
Output Control Setting
Amps
Volts
Minimum
75 to 150
6 to 11
Maximum
525
more than 41.2
