Peak Pilates – Deluxe & Reformer Models
Parts Manual
5
TOWER COMPONENTS
Vertical Lower
Block Coupler (2)
804-002
Pole Set
Cover (2)
804-008-1
Pulley Plate
Lock (2)
804-006
Cap Screw(2)
M6X70
804-022
Rubber
Bumper (2)
804-055
Spacer (2)
804-056
Quick Release
Pin (2)
804-510
Lock Washer (12)
804-035
Eye Bolt (19)
804-012
M6 Hex Nut (12)
804-036
Push Through
Block Mount (2)
804-007
Pole Set
Cover (2)
804-008
Cap Screw (30)
M6X35
804-021
Cap Screw (8)
M6X16Long
804-014
Vertical Upper
Block Coupler (2)
804-005
