Connection diagram, Powerwave – Lincoln Electric POWER WAVE IM713-B User Manual
Page 39
F-6
CONNECTION DIAGRAM
F-6
POWER WAVE® 655/R
K1796
COAXIAL
WELD
CABLE
User
supplied
work
lead
User
supplied
electrode
lead
-
+
POWERWAVE
CONTROL
CABLE
K1805-1
WORK
SENSE
LEAD
K940
DEVICENET
CABLE
K1804-1
CONTROL
CABLE
OR
K1804-2
AND
ANY
K1795
CONTROL
CABLE
CONTROL
CABLE
K1805-1
User supplied
electrode lead
User supplied
work lead
Robotic Set Up, Electrode Positive, CV/Pulse
Configuration
