9
LITTLE
WONDER
BLOWER
SET-UP INSTRUCTIONS
SET-UP INSTRUCTIONS
1. Open box. Remove upper handle and cardboard
insert.
2. Lay box down with blower housing up. Use lower
handle to roll unit out of the box.
3. Locate hardware package.
4. Install upper handle to lower handle with (4) 3/8-16
x 1-3/4 carriage bolts and (4) 3/8-16 flanged nylon
insert nuts from the hardware package. Tighten the
nuts securely but not so much as to crush the tube.
(Figure 1)
5. If equipped with a Throttle Cable: Route the
throttle cable in front of lower handle crossbar.
Install to the left side of the upper handle with (2)
10-32 x ½ thread forming screws from the hardware
package. (Figure 2)
6. If equipped with a Throttle Cable: Secure the
throttle cables to the handle tubes with cable ties
from the hardware package. Trim off excess.
(Figure 3)
7. Fill the engine with oil to the level indicated on the
dipstick. Fill the fuel tank with clean, fresh regular
grade unleaded gasoline.
FIGURE 1
FIGURE 2
FIGURE 3
